Danmark DFS Visual 500 VFR Chart
The Aeronautical Chart Visual 500 is the first aeronautical chart for Europe, which corresponds in quality and design to the Aeronautical Chart ICAO 1:500,000 and is therefore the optimal chart for VFR flights to neighbouring countries. Due to the selected sheet layout, each neighbouring country is extensively illustrated on the country editions.
The Visual 500 contains the latest and currently valid topography and air traffic control information such as
- VFR reporting points
- aerodromes with name, place name and frequency as well as length and orientation of the runway and location of the traffic circuit
- Information on the aerodrome circuit, display of aerodrome heights
- FIS sectors with frequencies
- Gliding areas, hang gliders and microlight aircraft areas, parachute jump areas and balloon launch sites
- radio navigation equipment (NDB, VOR, VOR/DME, VORTAC) with name, frequency and Morse code identification
- Aviation Obstacles and Maximum Elevation Figures
- Isogons
- Motorway designations
- Integrated coordinate ruler
The back of the card displays the following information:
- ATIS and VOLMET frequencies
- Semi-circular flight altitudes VFR and VFR remote control
- Information on the altimeter setting
- Light signals
